Drill 3D Automatic Measurement

Product Highlights:

• Supports multiple types of PCB boards, including various thicknesses and background inks;

• Supports various types of holes, such as laser drills, back drills, etc.;

• We have a strong R&D team to ensure the stability and high performance of our equipment;

• We have a vast customer base, and our rich experience guides us in leading the trend;

• We have a professional service team dedicated to supporting equipment initialization and upgrades.

Working Principle:

Through a 3D imaging system, using a light source perpendicular to the tested board from the top surface, the image is clearly presented (captured by the camera in real-time) and perceived. Subsequently, the image is transmitted to computer measurement software, which performs in-depth analysis using intelligent measurement tools.

The analysis includes key parameters such as the diameter, true circularity, and depth of circular holes on the specified PCB board, among others.
